Sauce high shear mixing tank

Applications

Sauce high shear mixing tank is widely used in food processing industries such as condiments, salad dressings, hot sauces, etc. It is particularly suitable for sauce production that requires efficient and uniform mixing and fine texture. The tank can quickly mix solid and liquid ingredients to enhance the flavor and taste of the product.

Features

Food grade 304/316 stainless steel ensures safety and hygiene. High shear agitator is used to achieve fast and uniform mixing and emulsification. PLC control system and CIP cleaning system are equipped to facilitate precise adjustment of stirring speed and time and cleaning of the tank.

Applications

Model	Volume (L)	Diameter （mm）	Heating power （Kw）	Heating method	Dimensions （mm）
JYH-JCJE-500	500	Φ900*800	2.2	Z-steam/D-electric	135011502250
JYH-JCJE-1000	1000	Φ1100*1000	/	Z-steam/D-electric	155013502450
JYH-JCJE-2000	2000	Φ1300*1500	3	Z-steam	185016502850
JYH-JCJE-3000	3000	Φ1600*1500	/	Z-steam	215019502950
JYH-JCJE-5000	5000	Φ1800*2000	/	Z-steam	235021503450

ABOUT JINGYE MACHINERY

Jiangxi Jingye Machinery Technology Co., Ltd. is a machinery manufacturing enterprise integrating technology R&D. We specializes in the production and sales of food, beverage, pharmaceutical and chemical machinery, sanitary fluid pump valve accessories, etc., and provides process design, manufacturing and installation of food and beverage production lines, liquid milk production line sterilization equipment, etc. Commissioning, technical training and after-sales service to turnkey overall engineering services.

The main products include: autoclave, pressure cooker, mixing tanks, jacketed pots, reaction tank, plate heat exchanger, fermentation tanks, blending tanks, hot and cold cylinders, centrifugal pumps, beverage pumps, etc. Widely applicated in food and beverage category include production lines for sauces, bone broth, hummus, syrup, milk, juice, protein drinks (soy milk), fresh milk, tea drinks, eight-treasure porridge, etc.

The company takes product quality excellence as its core and service quality as its goal. While digesting and absorbing advanced domestic and foreign technologies, it combines its own advantages to continuously innovate and make progress. In line with the business purpose of "customer interests first, product quality first", we provide our customers with high-quality products and services.
